Overview. .
.
Dimensions.
141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2»). .
.
UniFi Application Suite. .
.
.
Network.
Yes. .
.
Managed UniFi Devices.
30+. .
.
Simultaneous Users Connected.
300+. .
.
Default WAN Ports.
(1) 2.5 GbE RJ45. .
.
LAN Ports.
(4) GbE RJ45. .
.
IDS/IPS Throughput.
1 Gbps. .
.
Form Factor.
Compact desktop. .
.
.
Security. .
.
Stateful Firewall.
Yes. .
.
Application-Aware Layer 7 Firewall.
Yes. .
.
DPI & Traffic Identification.
Yes. .
.
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps).
Yes. .
.
Content Filtering.
Yes. .
.
Intrusion Prevention (IPS/IDS).
Yes. .
.
Ad Blocking.
Yes. .
.
IDS/IPS Signatures.
55,000+ with CyberSecure. .
.
VLAN/Subnet-based Traffic Segmentation.
Yes. .
.
.
VPN & SD-WAN. .
.
License-Free SD-WAN.
Yes. .
.
Site-to-Site VPN. .
.
.
.
Site Magic.
Yes. .
.
.
.
IPsec.
Yes. .
.
.
.
OpenVPN.
Yes. .
.
VPN Server. .
.
.
.
Identity Endpoint One-Click VPN.
Yes. .
.
.
.
Teleport Zero-Configuration VPN.
Yes. .
.
.
.
WireGuard.
Yes. .
.
.
.
OpenVPN.
Yes. .
.
.
.
L2TP.
Yes. .
.
VPN Client. .
.
.
.
OpenVPN.
Yes. .
.
.
.
WireGuard.
Yes. .
.
.
Networking. .
.
Multi-WAN Load Balancing.
Yes. .
.
Dynamic Routing. .
.
.
.
OSPF.
Yes. .
.
Advanced QoS.
Yes. .
.
Multicast DNS (mDNS).
Yes. .
.
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT).
Yes. .
.
Integrated RADIUS Server.
Yes. .
.
RADIUS over TLS (RadSec).
Yes. .
.
Additional Internet Failover with LTE Backup.
Yes. .
.
Internet Quality and Outage Reporting.
Yes. .
.
MAC Address Table Size.
2,000. .
.
Policy-based WAN and VPN Routing.
Yes. .
.
Customizable DHCP Server.
Yes. .
.
IPv6 ISP Support.
Yes. .
.
IGMP Proxy.
Yes. .
.
.
Hardware. .
.
Max. Power Consumption.
6.2W. .
.
Power Method.
USB type C (5V DC/3A). .
.
Power Supply.
USB type C (5V DC/3A) (Adapter included). .
.
Supported Voltage Range.
100240V AC. .
.
Processor.
Quad-core ARM® Cortex®-A53 at 1.5 GHz. .
.
System Memory.
3 GB. .
.
On-board Storage.
16 GB. .
.
Weight.
520 g (1.1 lb). .
.
Enclosure Material.
Polycarbonate. .
.
LCM Display.
0.96» status display. .
.
Management.
Ethernet Bluetooth. .
.
Ambient Operating Temperature.
-10 to 40º C (14 to 104º F). .
.
LEDs. .
.
.
.
Ethernet.
Yes. .
.
Ambient Operating Humidity.
5 to 95% noncondensing. .
.
Certifications.
CE, FCC, IC. .
.
Button.
(1) Factory-reset. .
