Placa base para servidores y estaciones de trabajo con socket SP3 en formato ATX.
Principales Características…
* Single Socket SP3 (LGA4094) compatible con la familia de procesadores AMD EPYC serie 7002/7001.
* Admite 8 canales DDR4 3200/2933/2666/2400 RDIMM, LRDIMM 8 x ranuras DIMM.
* Admite 8x SATA3 6.0 Gb / s (desde 2x mini SAS HD), 1x SATA DOM y 2 x M.2.
* Soporta 2 X 10G LAN por Intel X550.
* Admite 4 PCIe3.0x 16, 3 PCIe 3.0×8.
* Soporta 2 OCulink.
| MB Physical Status | |
| Form Factor | – ATX |
| Dimensions | – 12» x 9.6» (30.5 cm x 24.4 cm) |
| Processor System | |
| CPU | – AMD EPYC™ 7002/7001 series processor family |
| Socket | – Single Socket SP3 (LGA4094) |
| System Memory | |
| Capacity | – 8 DIMM slots |
| Type | – Eight Channel DDR4 memory technology – Supports DDR4 RDIMM and LRDIMM |
| DIMM Size Per DIMM | – RDIMM: 32GB, 16GB, 8GB – LRDIMM: 128GB, 32GB |
| DIMM Frequency | – RDIMM: 3200/2933/2666/2400MHz – LRDIMM: 3200/2933/2666/2400MHz |
| Voltage | – 1.2V |
| Expansion Slot | |
| PCIe 3.0 x 16 | – PCIE1: Gen3 x16 link – PCIE3: Gen3 x16 link – PCIE5: Gen3 x16 link – PCIE7: Gen3 x16 link |
| PCIe 3.0 x 8 | – PCIE2: Gen3 x8 link – PCIE4: Gen3 x8 link – PCIE6: Gen3 x8 link |
| Storage | |
| SATA Controller | – 9 x SATA3 6.0 Gb/s (from 2x mini SAS HD and 1x SATA DOM port) |
| OCuLink for U.2 | – 2 |
| Ethernet | |
| Interface | – 10000/1000 /100 /10 Mbps by Intel® X550 |
| LAN Controller | – 2 x RJ45 10G base-T by Intel® X550 – 1 x RJ45 Dedicated IPMI LAN port by RTL8211E – Supports Wake-On-LAN – Supports Energy E_cient Ethernet 802.3az – Supports Dual LAN with Teaming function – Supports PXE – LAN1 supports NCSI |
| Management | |
| BMC Controller | – ASPEED AST2500 |
| IPMI Dedicated GLAN | – 1 x Realtek RTL8211E for dedicated management GLAN |
| Features | – Watch Dog – NMI |
| Graphics | |
| Controller | – ASPEED AST2500 |
| VRAM | – DDR4 128Mb |
| Rear Panel I/O | |
| VGA Port | – 1 x D-Sub |
| USB 3.1 Gen1 Port | – 2 |
| Lan Port | – 2+1 RJ45 Gigabit Ethernet LAN port – LAN Ports with LED (ACT/LINK LED and SPEED LED) |
| Serial Port | – 1 x COM port |
| UID Button/UID LED | – 1 |
| Internal Connector | |
| SATA DOM | – 1 |
| M.2 | – 2(M2_1: 2230/2242/2260/2280, SATA/PCIE(X4); M2_2:2230/2242/2260/2280/22110, SATA/PCIE(X4)) |
| Front LED | – 1 |
| Auxiliary Panel Header | – 1 (includes chassis intrusion, location button & LED, and front LAN LED) |
| TR1 Header | – 1 |
| TPM Header | – 1 |
| IPMB Header | – 1 |
| Fan Header | – 7 Fans x 6-pin (1CPU/4Front/2Rear) |
| ATX Power | – 1 x (24-pin) + 1 x (8-pin) + 1 x (4-pin) + 1 x (6-pin)(6 pin for GPU for PCIE Slot) |
| USB 3.1 (Gen1) Header | – 1 (supports 2 USB 3.0 ports) |
| USB 2.0 Header | – 1 |
| Speaker Header | – 1 |
| BMC_SMB Header | – 1 |
| Clear CMOS | – 1 |
| PSU SMB Header | – 1 |
| Onboard LED | |
| 80 Debug Port LED | – 1 |
| Fan Fail LED | – 1 (only Fan Fail LED) |
| System BIOS | |
| BIOS Type | – 32MB AMI UEFI Legal BIOS |
| BIOS Features | – Plug and Play (PnP) – ACPI 2.0 Compliance Wake Up Events – SMBIOS 2.8 Support – ASRock Rack Instant Flash |
| Hardware Monitor | |
| Temperature | – CPU Temperature Sensing – MB/TR1/Card side Temperature Sensing |
| Fan | – CPU/Rear/Front Fan Tachometer – CPU Quiet Fan (Allow CPU Fan Speed Auto-Adjust by CPU Temperature) – CPU/Rear/Front Fan Multi-Speed Control |
| Voltage | – Voltage Monitoring: Vsoc,Vcpu, VCCM, VPPM, 3V/5V/12V, +BAT, 3VSB, 5VSB |
| Support OS | |
| OS | Microsoft® Windows® – Server 2012 R2 (64 bit) – Server 2016 (64 bit) Linux Virtual: * Please refer to our website for the latest OS support list. |
| Environment | |
| Temperature | Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C |
